Geodesic Dome Tent – Jumei Tent Technology Co., Ltd.

Geodesic Dome Tent

Geodesic Dome Tent

Geo Dome Tent - Unique, modern, and amazing appearance

Geodesic dome tent is a new and unique style of tent. It is not only served as the event dome for a showcase space at exhibitions and events, but also perfectly suited for use for VIP or temporary spaces for parties, or as dining or shopping spaces, or as a temporary or semi-permanent venue for interactive entertainment, yoga or meditation session. In the meanwhile, the geodesic dome is also popularly used as a glamping dome for accommodation at glamping resorts, hotels, parks, Airbnb hosting, or simply as an alternative way of spending time in your garden or backyard.

Get a FREE Quote Now!

We provide many sorts of geodesic dome tents including glamping dome tent, event dome tent, open geo dome tent, amphitheatre style tent, projection dome tent and so on. These tents are widely used for glamping resorts, events, festivals, weddings, trade show, sport events etc.

We provide various diameter geodesic dome tents from 3m to 80m. And you can request the customization service. We also provide different roof cover to meet your needs, including transparent or different colors.

Specifications & Features

Series Diameter
(m/feet)
Top Height
(m)
Frame Strut
(mm)
Floor Area
(㎡)
Capacity
(persons)
Glamping Dome Tent
JGD
(Glamping Dome Tent)
4m 13ft 2.5 Φ26*1.5 12.57 2
5m 16ft 3 Φ26*1.5 19.60 2-4
6m 20ft 3.5 Φ26*1.5 28.26 2-4
7m 23ft 3.7 Φ26*1.5 38.48 1-4
8m 26ft 4 Φ26*1.5/Φ32*2 50.24 2-6
10m 32ft 5 Φ26*1.5/Φ32*2 78.5 2-6
Series Diameter
(m/feet)
Top Height
(m)
Frame Strut Size
(mm)
Floor Area
(㎡)
Capacity
(People sitting)
Capacity
(People standing)
Event Dome Tent
JED
(Event Dome Tent)
6m 20ft 3.5 Φ26*1.5 28.26 10-15 25
8m 26ft 4 Φ26*1.5/Φ32*2 50.24 25-30 55
10m 32ft 5 Φ32*2 78.5 50-70 100
15m 50ft 7.5 Φ32*2 177 120-150 260
20m 66ft 10 Φ42*2 314 250-300 420
25m 82ft 12.5 Φ42*2 491 400-450 650
30m 98ft 15 Φ48*2.5 706.5 550-600 800
35m 115ft 17 Φ48*2.5 961 850-900 1100
40m 131ft 18 Φ60*3 1256 1000-1100 1350
Frame materialSteel Q235 (hot-dip galvanized) or Hard pressed aluminum alloy T6061/T6
Fabric cover
  • High quality double PVC-coated polyester textile;
  • 850g/sqm white or transparent PVC Fabric
  • 100% waterproof; flame retardant to DIN4102 B1, M2, CFM; UV resistant, tear-resistant, self-cleaning ability, etc.
Fabric color optionWhite, yellow, transparent and customized
Allowed temperature condition-30 degree Celsius +70 degree Celsius
Wind load100km/h or customized.
Snow load75kg/sqm (snow can’t stay if use big degree roof pitch design)
Other featuresEasy to assemble and disassemble
No pole inside, 100% available interior space
  • Anchoring
  • Lining and curtain
  • Glass door units
  • Transparent, color or image PVC cover
  • Flooring system
  • Weight plate
  • Vent hole, exhaust fan
  • Air conditioner
  • Glass window
More accessories are available, please feel free to contact us if you need more information.
